Configuration du serveur
Tout ce que vous devez savoir pour configurer votre serveur !
Fichier de configuration du serveur
Le fichier de configuration du serveur Config.toml Ce fichier sera toujours remplacé par le bon modèle après le chargement du serveur.
nanos world Config files use TOML (Tom's Obvious, Minimal Language), please refer to https://github.com/toml-lang/toml for more information and syntax.
loading...
Paramètres détaillés
The Config file is split into a few sections. Each one is described below with its type, default value and accepted range.
The server rewrites Config.toml on every startup, after applying the Command Line Parameters and validating each value. Any comment you add, unknown key, or out-of-range value will be discarded or reset, the log will tell you exactly which setting got reset and to what.
[discover]
How your server presents (and announces) itself.
| Paramètre | Type | Par défaut | Description |
|---|---|---|---|
name | string | "nanos world server" | Name of the Server, as displayed in the Server List |
description | string | "" | Description du serveur. Clamped to 200 characters |
language | string | "global" | Country code (e.g. br, us, de) used to display a country flag in the server list |
ip | string | "0.0.0.0" | Address the server binds to, for both the game socket and the built-in HTTP Server. We recommend leaving it 0.0.0.0, which binds to every interface |
port | integer | 7777 | Server main Port, used for both game traffic (UDP) and the built-in HTTP Server (TCP). Range 1024 - 65535 |
query_port | integer | 7778 | Server query Port (UDP), used by the Server List and by query tools. Range 1024 - 65535, and must be different from port |
announce | boolean | vrai | Whether to announce the server in the Server List. A non-announced server is still joinable through Direct Connect |
dedicated_server | boolean | vrai | true runs a Dedicated Server: requires port forwarding and gives the fastest connection.false runs it as P2P, which hands out a fake IP for players to connect through Steam Datagram Relay, no port forwarding needed, but higher latency, and the send rate is capped at 1024 KB/s by the relay service regardless of max_send_rate |
[general]
| Paramètre | Type | Par défaut | Description |
|---|---|---|---|
max_players | integer | 64 | Nombre maximum de joueurs autorisés à rejoindre. Range 1 - 999 |
password | string | "" | Password required to connect. Leave it blank for no password required |
string | "" | Server authentication token, used to authorize Vault downloads, through the CLI, through --auto_download, and when fetching Packages/Assets you own | |
banned_ids | string list | [] | List of banned nanos account IDs. Banned players are rejected at connection time |
[game]
| Paramètre | Type | Par défaut | Description |
|---|---|---|---|
map | string | "default-blank-map" | script paquets à charger. See Map & Level |
game_mode | string | "" | game-mode package to load, you can only load one game-mode at once |
packages | string list | [] | script paquets à charger |
assets | string list | [] | Additional Asset Packs to force loading, on top of the ones the loaded Packages/Map already require |
loading_screen | string | "" | loading-screen package to load, you can only load one loading-screen at once |
[custom_settings]
A free-form table of your own values, made available to every Package through Server.GetCustomSettings(). Values can be strings, integers, floats or booleans.
[custom_settings]
max_props = 1000
enable_pvp = true
welcome_message = "have fun!"
game-modes can declare which Custom Settings they accept, so they show up in the New Game screen, see Custom Settings. The whole table can also be passed on the command line with --custom_settings "max_props = 1000, enable_pvp = true".
[debug]
| Paramètre | Type | Par défaut | Description |
|---|---|---|---|
log_level | integer | 1 | Which Log level to output: 1 normal, 2 debug, 3 verbose. Levels 2 and 3 are noisy, use them to investigate a problem, not in production |
async_log | boolean | vrai | Writes logs from a separate thread, which is faster. Set it to false when debugging a crash, so the last lines before the crash are guaranteed to be flushed |
profiling | boolean | false | Enables Performance Profiling Logs, which report how long each internal operation took. Useful to find what is making your server tick slow. Can also be toggled at runtime with the profiling console command |
[optimization]
| Paramètre | Type | Par défaut | Description |
|---|---|---|---|
max_tick_rate | integer | 30 | Server Tick in Hz, how many times per second the server loop runs. Range 15 - 120. Everything (network receive/send, Lua events, timers, etc) happens inside this loop, so a higher value is more responsive but multiplies CPU usage. 30 Hz means the server has 33ms to do all its work per tick, we recommend leaving it 30 |
max_sync_rate | integer | 30 | Max actors sync rate in Hz, how often actors location/rotation/velocity are synchronized. Range 1 - 30, and naturally limited by max_tick_rate. This value is also sent to the clients, so they sync back at the same rate. Lowering it is the cheapest way to cut bandwidth on servers with many moving actors, at the cost of less precise movement |
max_send_rate | integer | 1024 | Max network send rate per client, in KB/s. Range 128 - 16384. Recommended setting to the lowest value that still fits your traffic, higher rates may negatively impact the server performance when having players with bad connections. P2P servers are capped to 1024 KB/s by Steam Datagram Relay. Can be changed at runtime with the max_send_rate console command |
max_file_transfer_rate | integer | 1024 | Max file transfer rate per client, in KB/s, how fast Packages and Assets files are pushed to a connecting player. Range 128 - max_send_rate; anything above max_send_rate is clamped down to it. Lower it to keep downloads from starving the gameplay traffic of players already in game |
compression | integer | 1 | Compression level applied to several networking operations. 0 disables it, 1 is the fastest and already provides a good compression, 9 is the slowest but has the highest compression ratio. See Compression below |
distance_optimization | integer | 4 | Reduces synchronization of actors that are far away from each player. 0 disables it, 4 is a good middle term, 9 is the most aggressive. See Distance Optimization below |
Compression
The server compresses (deflate) whole payload blocks before they go on the wire. The compression setting is the deflate level used: 0 disables it entirely, 1-9 trade CPU for ratio.
Scripts can read it with Server.GetCompressionLevel().
What gets compressed
| Data | When it is compressed |
|---|---|
Package client files: everything under a Package's Client/ and Shared/ folders, plus the generated Package.toml | Once, when the Package is loaded. The compressed copy is what stays in memory and is served to every player, over both socket transfer and HTTP |
| Client requirements: the manifest of every file (name, hash, size) a joining player must have | Rebuilt whenever Packages/Assets change |
| Loaded assets list | Rebuilt whenever Asset Packs change |
| Entity construction data: the scripting part of an entity's state (its Values, custom data) sent when a player needs to spawn it | Rebuilt whenever that entity's data changes |
Server networked values: the table set with Server.SetValue(key, value, true), sent to joining players | Rebuilt whenever a value changes |
| Remote event parameters: big tables sent with Events.Call/BroadcastRemote() | Per call |
Files whose extension is already a compressed format are skipped, since deflating them again only burns CPU: .png, .jpg, .jpeg, .webp, .webm, .gif, .ogg, .mp3, .mp4, .zip, .rar, .7z, .woff2.
Set log_level = 2 to see per-group summaries (Compressed Package 'x' Client Files from 4.2 MB to 900.1 KB (78.6%)), or log_level = 3 to get a line for every single block that gets compressed.
Distance Optimization
For each player, and for each actor being synchronized, the server computes a relevancy based on the distance between them:
relevancy = clamp(100 - ((distance_in_units / 1000) - 1) * distance_optimization * multiplier, 0, 100)
The relevancy is the percentage of ticks in which that actor's snapshots are actually sent to that player: 100 means always, 0 means never.
Relevancy by distance across all levels:
| Distance | Lvl. 1 | Lvl. 2 | Lvl. 3 | Lvl. 4 | Lvl. 5 | Lvl. 6 | Lvl. 7 | Lvl. 8 | Lvl. 9 |
|---|---|---|---|---|---|---|---|---|---|
| 1,000 units | 100% | 100% | 100% | 100% | 100% | 100% | 100% | 100% | 100% |
| 5,000 units | 96% | 92% | 88% | 84% | 80% | 76% | 72% | 68% | 64% |
| 10,000 units | 91% | 82% | 73% | 64% | 55% | 46% | 37% | 28% | 19% |
| 20,000 units | 81% | 62% | 43% | 24% | 5% | 0% | 0% | 0% | 0% |
| 30,000 units | 71% | 42% | 13% | 0% | 0% | 0% | 0% | 0% | 0% |
| 40,000 units | 61% | 22% | 0% | 0% | 0% | 0% | 0% | 0% | 0% |
And the distance at which an actor stops being synchronized entirely:
| Level | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 |
|---|---|---|---|---|---|---|---|---|---|
| Cut-off distance | 101,000 | 51,000 | 35,000 | 26,000 | 21,000 | 18,000 | 16,000 | 14,000 | 13,000 |
This only throttles unreliable traffic, such as movement snapshots and transient actions (e.g. Jump). Reliable data (spawning and destroying entities, remote events, value changes) is always delivered in full, no matter the distance.
Scripting can bias the formula per entity with Actor:SetDistanceOptimizationMultiplier() and per player with Player:SetDistanceOptimizationMultiplier(), both multipliers are applied together. A value below 1 keeps the actor relevant for longer (use it for something that must stay smooth at range, like a scaled up actor or character), above 1 culls it sooner, and 0 makes it always relevant.
The level can also be changed while the server is running with the distance_optimization console command.
Logo Image
It is possible to have a custom image to be displayed in the server list. For that, add a file called Server.jpg besides the server executable with the logo you wish. The recommended size is 300x150.
You can pass a JPG image URL to --logo parameter to download and use a image from the web instead of placing it physically in the folder.
Server Logo feature is only available for for Dedicated Servers.
Map & Level
The Map (or Level) is defined in the Server's config file, this map will be loaded when the player joins the server in the client side.
To configure a map, please refer to Packages Guide to create a Map Package pointing to the correct Asset.
nanos world counts on (for now) 4 built-in maps: default-blank-map, default-empty-map, default-ocean-map and default-testing-map which can be used in your server without needing to download any Package/Asset Pack.
Console du serveur
Commandes intégrées
| Commande | Parameters | Description |
|---|---|---|
chat | \<message> | Envoie un message dans le chat |
clear | Clears the console | |
kick | \<player_id> \<reason> | Kicks a player by it's ID |
map | \<map_package> | Changes the map to another map Package, reloading all Packages and reconnecting the Players |
restart | Restarts the server, reloading all Packages and reconnecting the Players | |
stop | Arrête le serveur | |
players | Lists all Players connected | |
password | \<new_password> | Changes the server password |
profiling | \<0-1> | Enables/Disables Performance Profiling Logs for debugging |
log_level | \<1-3> | Changes the log level |
max_send_rate | \<128-16384> | Changes the max send rate per client |
max_file_transfer_rate | \<128-max_send_rate> | Modifie le taux de transfert de fichier maximum par client |
distance_optimization | \<0-9> | Sets the distance optimization level |
package run | \<package_name> \<lua_code> | Runs a code in a Package |
package reload all | Reloads all Packages and restarts the Lua Virtual Machine | |
package reload | \<package_names...> | Reloads Packages |
package unload | \<package_names...> | Unloads Packages |
package load | \<package_names...> | Loads Packages |
package hotreload | \<package_names...> | Reloads all files but keeps the memory as is |
Commandes personnalisées
It is possible to define custom commands as well, for that please refer to Console.RegisterCommand().
Paramètres de ligne de commande
Il est possible de remplacer la configuration du serveur avec les paramètres de ligne de commande.
| Paramètre | Type de valeur | Description |
|---|---|---|
--name | string | Nom du serveur |
--description | string | Description du serveur |
--logo | string | Server Logo (downloads the image in-memory) |
--password | string | Mot de passe du serveur |
--ip | string | Address the server binds to |
--steam_app | game or playtest | Which Steam App the server runs as. Players can only join servers running the same Steam App they are playing on Default is playtest |
--map | string | Map Package to load |
--port | 1024-65535 | --http_port |
--query_port | 1024-65535 | Server Query port (must be different than server port) |
--announce | 0 or 1 | Whether to announce the server in the Server List |
--game_mode | string | Mode de jeu du serveur |
--loading_screen | string | Écran de chargement du serveur |
--packages | string list | Packages du serveur |
--assets | string list | Assets du serveur |
--token | string | Server authorization token |
--max_players | 1-999 | Nombre de joueurs autorisés |
--dedicated_server | 0 or 1 | If to start as a Dedicated Server or P2P |
--async_log | 0 or 1 | If to use async or sync logs (async provides better performance) Default is 1 |
--log_level | 1, 2 or 3 | If to use Normal 1, Debug 2 or Verbose 3 logs |
--custom_settings | toml string | A list of Custom Settings to be passed to scripting in toml format |
--compression | 0-9 | Sets the compression level to use in some networking operations0 disables it, 1 is the fastest and 9 is the slower but highest compression ratioSee Compression |
--save | flag | If to save the passed parameters in Config.toml |
--profiling | flag | Activer les logs de profilage pour le débogage |
--auto_download | flag | Télécharger automatiquement les Packages et les Assets depuis le Vault si nécessaire |
--use_vault_assets_lean | flag | Only downloads the Asset Pack's .toml configuration files from Vault |
--log_show_thread | flag | Shows the current running thread of each outputted log |
--max_tick_rate | 15-120 | Sets the server max tick rate in Hz (ticks per second) |
--max_sync_rate | 1-30 | Sets the max actors sync rate in Hz (syncs per second), naturally limited by max_tick_rate |
--max_send_rate | 128-16384 | Sets the server max send rate per client in KB/s |
--max_file_transfer_rate | 128-max_send_rate | Sets the server max file transfer rate per client in KB/s Values above max_send_rate are clamped down to it |
--distance_optimization | 0-9 | Sets the distance optimization level to improve network usage by reducing sync from distant actors0 disables it, 4 is a good middle term, 9 is the most aggressiveSee Distance Optimization |
--thread_pool_count | 0-any | Sets the number of threads initialized to execute async operations (e.g. from HTTP, Database, File) Default is 8 (or the number of CPU cores) and 0 disables the pool and always start a new thread for each async operation |
--enable_unsafe_libs | flag | Enables executing the methods os.execute, os.rename, os.remove, os.exit, os.getenv, os.tmpname, os.setlocale, dofile, loadfile and all io.* on server sideCaution: those methods may allow malicious operations to run on your server, make sure you know what you are doing |
Flag Value Types don't require any argument, just pass the parameter like --profiling.
Two special parameters must be passed as the first argument:
--cliruns the Command Line Interface instead of starting the server, e.g../NanosWorldServer.exe --cli install package sandbox.--tracy(Linux only, throughNanosWorldServer.sh) starts the server build with the Tracy Profiler integration. On Windows, runNanosWorldServerTracy.exeinstead.
One-liner Server Configuration
With Command Line Parameters and Command Line Interface (CLI), it is also possible to automate the full server installation, here's an example:
- Windows
- Linux
Installs all needed Packages (this will install needed Assets as well), then starts the server with all configs set:
./NanosWorldServer.exe --cli install package sandbox battlefield-kill-ui ts-fireworks-tools
./NanosWorldServer.exe --name "nanos world Amazing Sandbox" --description "Awesome Sandbox Server" --map "default-testing-map" --game_mode "sandbox" --packages "battlefield-kill-ui,ts-fireworks-tools" --port 7777 --query_port 7778 --max_players 32 --logo "https://i.imgur.com/vnB8CB5.jpg"
Or, just start the server passing with all configs set and auto downloads the packages and assets if needed:
./NanosWorldServer.exe --name "nanos world Amazing Sandbox" --description "Awesome Sandbox Server" --map "default-testing-map" --game_mode "sandbox" --packages "battlefield-kill-ui,ts-fireworks-tools" --port 7777 --query_port 7778 --max_players 32 --auto_download --logo "https://i.imgur.com/vnB8CB5.jpg"
Installs all needed Packages (this will install needed Assets as well), then starts the server with all configs set:
./NanosWorldServer.sh --cli install package sandbox battlefield-kill-ui ts-fireworks-tools
./NanosWorldServer.sh --name "nanos world Amazing Sandbox" --description "Awesome Sandbox Server" --map "default-testing-map" --game_mode "sandbox" --packages "battlefield-kill-ui,ts-fireworks-tools" --port 7777 --query_port 7778 --max_players 32 --logo "https://i.imgur.com/vnB8CB5.jpg"
Or, just start the server passing with all configs set and auto downloads the packages and assets if needed:
./NanosWorldServer.sh --name "nanos world Amazing Sandbox" --description "Awesome Sandbox Server" --map "default-testing-map" --game_mode "sandbox" --packages "battlefield-kill-ui,ts-fireworks-tools" --port 7777 --query_port 7778 --max_players 32 --auto_download --logo "https://i.imgur.com/vnB8CB5.jpg"
Messages et erreurs communs de la console
Server Tick too/extreme high! Verify the server performance! Server got stuck for Xms...
It means the server got stuck for X milliseconds. The warning (yellow) is not something to worry about, but too many messages in red could mean your server infrastructure is not that good or your scripting code is not that optimized.
By default the server runs at 30 ticks per second (or the max_tick_rate configured in the Config.toml), the server runs in an infinite loop in that frequency, and inside that loop all server operations are executed, such as receiving and sending network packets, triggering lua events, executing functions or callbacks, and so on.
At 30 ticks per second, each tick has about 33 milliseconds to do all its work. If a single tick takes longer than that, this warning will show up.
In some shared VPS, this warning may appear up more frequently due how the VPS handles the scaling of it's machines, sometimes the provider may think your VPS is "idle" (due nanos world server using extremely low CPU) and may decrease your processing power, causing this warning show up as well.
Lua Stack Error: Should be X, is Y...
This is an internal error and should not supposed to happen. Those are guards set around our Lua Scripting implementation to prevent bad things from happening. If this error appears it means a implementation bug happened. Please communicate immediately with the devs, and if possible how to reproduce that!
...Was it supposed to happen?
Those FATAL errors usually shouldn't happen, if you experience any, please let us know.
